VESSEL NAME
REF802
TYPE
REEFER CARRIER
DEEP FREEZING OR NOT
NO
FLAG
LIBERIA
PORT OF REGISTRY
MONROVIA
BUILT YEAR
1993
BUILT PLACE
IWAGI ZOSEN CO.,LTD, JAPAN
CLASSIFICATION
NK
CLASS NOTATION
RMC.CA(-25/32 eqF for ACh.CA), CHG, MPP, LSA, RCF, M0, AFS
SS
-
DD
-
LOA (M)
141.8
LBP (M)
133
BEAM (M)
22.8
DEPTH (M)
13.01
SUMMER DRAFT (M)
8.8
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
9829
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
3538
PANAMA NT (MT)
9028
SUEZ NT (MT)
-
SUMMER DWT (MT)
10466
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
LDT (MT)
-
DISPLACEMENT (MT)
-
GEAR(S)
CRANES:
2 x 10MT, 25M
2 x 30MT, 25M(MAX 20MT)
OUTREACH: 13.6M
M/E(S)
HITACHI B & W 7S50MC, 2T 7CYL, 12460BHP,123RPM
M/E POWER (KW)
9300
A/E(S)
YANMAR: 3 x 883KW
GENERATOR(S)
3 x 1000KVA, 800KW, 450V, 60HZ
SHAFT GENERATOR(S)
-
PROPELLER(S)
FPP, LB10，119RPM
COOLING SYSTEM (COMPRESSOR)
3 x 250KW, MYCOM FU200 MUD 2-VE
BRINE
R22 AS MEDIUM
SPEED/CONSUMPTIONS
BALLAST: 20KTS, 32MT IFO + 2.5MT IFO
FROZEN COMMIDITIES: 18.5KTS, 33.5MT IFO + 5MT IFO
FUEL TYPE
IFO380
BUNKER CAPACITY (CBM)
1510
TANKS CAPACITY (CBM)
MGO: 215
NUMBER OF CARGO HOLDS
4
HATCH NUMBER
4
HATCH TYPE
-
HATCH SIZE (M)
7.6 x 7.1
HEIGHT OF HATCH COAMING (M)
-
COMPARTMENT(S)
20
DECK(S)
-
DECK HEIGHT (M)
≥2.2
CARGO CAPACITY (CBFT)
539648
CARGO CAPACITY (CBM)
15295
FLOOR SPACE CAPACITY (SQM)
6067.65
GRATING/DECK STRENGTH
MAX 5 MT, (FORKLIFT TO BE EQUIPED WITH MIN 4 AIRTYERS)
TEMPERATURE ZONE(S)
8，1UPDA, 1BCD,2UPDAB,2CD,3UPDAB,3CD,4UPDAB,4CD
TEMPERATURE (℃)
-30/+13
TYPE OF VENT SYSTEM
-
VENT (TIMES/HOUR)
90
AIR CHANGE (TIMES/HOUR)
4
PALLET(S)
-
CONTAINER CAPACITY
65FEU
REEFER PLUG(S)
65
SIDE DOOR(S)
-
FENDER(S)
-
ANCHOR CHAIN(S)
-
USDA CERTIFICATE
-
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
USD 4.80 MILLION
REMARK(S)
-
