VESSEL NAME
REF938
TYPE
REEFER CARRIER
DEEP FREEZING OR NOT
NO
FLAG
CHINA
PORT OF REGISTRY
ZHOU SHAN
BUILT YEAR
2024
BUILT PLACE
CHINA
CLASSIFICATION
CCS
CLASS NOTATION
CRS(NO.1、2、3、4 Hold -35℃, 35℃ Max. Sea Water );Ice Class B2 (dmax, f=9.40m, dmax, m=10.00m, dmax, a=10.60m, dmin, f=3.00m, dmin, m=4.50m, dmin, a=6.00m, PB=3602kW);PSPC(B)
SS
2029-01
DD
2027-01
LOA (M)
157.3
LBP (M)
147.46
BEAM (M)
23.3
DEPTH (M)
13.7
SUMMER DRAFT (M)
9.03
WINTER DRAFT (M)
8.84
TROPICAL DRAFT (M)
9.22
GT (MT)
13032
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
5960
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
12487
WINTER DWT (MT)
11851.3
TROPICAL DWT (MT)
13561.2
LDT (MT)
8890.3
DISPLACEMENT (MT)
21377.5
GEAR(S)
DERRICKS, 8 x 5MT
M/E(S)
STX-MAN 6S50MC -C7.1, 9480KW @127RPM
M/E POWER (KW)
9480
A/E(S)
3 SETS 6210ZLD-5, 662kw @750RPM
1 SET Z6180ZLD-13A 440KW@1000RPM
GENERATOR(S)
3 SETS 1FC6 506-8SA42, 600KW, 400V
EMERGENCY WEI CHAI WP10CD264E200. 264KW×1500rpm
SHAFT GENERATOR(S)
PROPELLER(S)
-
COOLING SYSTEM (COMPRESSOR)
R507A
3 SETS BING SHAN CJJZLG20FW
1 SET BING SHAN CJJZLG16FW
SPEED/CONSUMPTIONS
18.9 KNOTS MAX
14 KNOTS @ 21 T IFO380
FUEL TYPE
IFO180, MDO
BUNKER CAPACITY (CBM)
IFO180 1839.40CBM, MDO 2271.73CBM
TANKS CAPACITY (CBM)
FW 1285.74CBM
NUMBER OF CARGO HOLDS
4
HATCH NUMBER
4
HATCH TYPE
SIDE ROLLING
HATCH SIZE (M)
4*6.72 x 6.80 M
HEIGHT OF HATCH COAMING (M)
-
COMPARTMENT(S)
16
DECK(S)
4
DECK HEIGHT (M)
≥2.7M
CARGO CAPACITY (CBFT)
651997
CARGO CAPACITY (CBM)
18462.49
FLOOR SPACE CAPACITY (SQM)
GRATING/DECK STRENGTH
-
TEMPERATURE ZONE(S)
TEMPERATURE (℃)
-35
TYPE OF VENT SYSTEM
VERTICAL
VENT (TIMES/HOUR)
-
AIR CHANGE (TIMES/HOUR)
-
PALLET(S)
-
CONTAINER CAPACITY
REEFER PLUG(S)
-
SIDE DOOR(S)
-
FENDER(S)
4
ANCHOR CHAIN(S)
P:10S; S:11S , φ60，AM3
USDA CERTIFICATE
-
INSURANCE
-
CREW
59
ACCOMMODATION
-
INSPECTION
CHINA
DELIVERY
CHINA
PRICE
BUYERS OFFER
REMARK(S)
