VESSEL NAME

REF943

TYPE

REEFER CARRIER

DEEP FREEZING OR NOT

NO

FLAG

CHINA

PORT OF REGISTRY

SHIDAO

BUILT YEAR

2022

BUILT PLACE

WEIHAI DONGHAI SHIPYARD CO., LTD.

CLASSIFICATION

CCS

CLASS NOTATION

★CSA★CSM,Refrigerated Cargo Ship,PSPC(B);CRS(NO.1、2、3、4Hold -25℃, 35℃ Max.Sea Water);Ice Class B; FTP;BRC;EEDI(III)

SS

2027-01

DD

2026-09

LOA (M)

136

LBP (M)

126.4

BEAM (M)

19.6

DEPTH (M)

11.5

SUMMER DRAFT (M)

7.6

WINTER DRAFT (M)

-

TROPICAL DRAFT (M)

-

GT (MT)

8141

PANAMA GT (MT)

-

SUEZ GT (MT)

-

NT (MT)

4314

PANAMA NT (MT)

-

SUEZ NT (MT)

-

SUMMER DWT (MT)

9271

WINTER DWT (MT)

-

TROPICAL DWT (MT)

-

LDT (MT)

1474

DISPLACEMENT (MT)

14517.2

GEAR(S)

DERRICKS 8 x 5 MT

M/E(S)

MAN 6S35MC-C9.2, 4500 KW, 144RPM

M/E POWER (KW)

4500

A/E(S)

3 SETS ANQING 6DE-18 680KW @ 750RPM 1 SET WEICHAI 330KW @ 1000RPM

GENERATOR(S)

3 SETS HFC6562-84K 635KW @ 750RPM 1 SET 300KW @ 1000RPM; EMERGENCY WEICHAI TBD226B-6CD5 132KW @ 1500RPM

SHAFT GENERATOR(S)

450KW, AC400V @750RPM

PROPELLER(S)

FPP, 5 BLADES, DIAMETER 4600MM, 144RPM

COOLING SYSTEM (COMPRESSOR)

R507A BINGLUN, 2 SETS ZCLG20MZJM 250KW @ 2960RPM BINGLUN, 2 SETS ZCLG16MZJM 136KW @ 2960RPM

SPEED/CONSUMPTIONS

13.8 KTS

FUEL TYPE

HFO, MDO

BUNKER CAPACITY (CBM)

HFO 701.93CBM, MDO 1442.89CBM

TANKS CAPACITY (CBM)

FW 466.65CBM

NUMBER OF CARGO HOLDS

4

HATCH NUMBER

4

HATCH TYPE

HYDRAULICALLY SPLIT

HATCH SIZE (M)

3*7.60 x 7.00M; 1*3.40 x 3.80M

HEIGHT OF HATCH COAMING (M)

1

COMPARTMENT(S)

12

DECK(S)

3

DECK HEIGHT (M)

≥2.70M

CARGO CAPACITY (CBFT)

418482

CARGO CAPACITY (CBM)

11855.54

FLOOR SPACE CAPACITY (SQM)

GRATING/DECK STRENGTH

-

TEMPERATURE ZONE(S)

TEMPERATURE (℃)

-25/+35℃

TYPE OF VENT SYSTEM

MECHANICAL

VENT (TIMES/HOUR)

30

AIR CHANGE (TIMES/HOUR)

30

PALLET(S)

CONTAINER CAPACITY

REEFER PLUG(S)

SIDE DOOR(S)

1 FOR EACH SIDE

FENDER(S)

4

ANCHOR CHAIN(S)

GRADE AM3, DIAMETER 50MM, 550M

USDA CERTIFICATE

-

INSURANCE

-

CREW

33

ACCOMMODATION

33 SINGLE ROOMS

INSPECTION

CHINA

DELIVERY

CHINA

PRICE

BUYERS OFFER

REMARK(S)
