VESSEL NAME
REF946
TYPE
REEFER CARRIER
DEEP FREEZING OR NOT
NO
FLAG
CHINA
PORT OF REGISTRY
ZHOU SHAN
BUILT YEAR
2024
BUILT PLACE
ZHEJIANG,CHINA
CLASSIFICATION
CCS
CLASS NOTATION
★CSA★CSM,Refrigerated Cargo Ship, CRS(No.1、2、3、4 Hold -30℃, 35℃ Max. Sea Water);PSPC(B);Ice Class B; BRC;G-ECO(CD25, BWM(T))
SS
2029-01
DD
2029-01
LOA (M)
134.73
LBP (M)
127
BEAM (M)
18.2
DEPTH (M)
10.35
SUMMER DRAFT (M)
6.9
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
6803
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
2850
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
7075
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
LDT (MT)
-
DISPLACEMENT (MT)
-
GEAR(S)
DERRICKS 4 x 2.5MT
M/E(S)
GUANGZHOU DIESEL GDF-J-ENG 6UEC33LSE-C2, 4650KW @156RPM
M/E POWER (KW)
4650
A/E(S)
-
GENERATOR(S)
3 SETS SB-HW4-500-6P, 500KW, 400V
SHAFT GENERATOR(S)
-
PROPELLER(S)
-
COOLING SYSTEM (COMPRESSOR)
BINGSHAN,LG16、LG20C7AB
SPEED/CONSUMPTIONS
15.5
FUEL TYPE
-
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
-
NUMBER OF CARGO HOLDS
4
HATCH NUMBER
4
HATCH TYPE
-
HATCH SIZE (M)
4*7.20×7.00
HEIGHT OF HATCH COAMING (M)
-
COMPARTMENT(S)
DECK(S)
2
DECK HEIGHT (M)
-
CARGO CAPACITY (CBFT)
283810
CARGO CAPACITY (CBM)
8039.95
FLOOR SPACE CAPACITY (SQM)
GRATING/DECK STRENGTH
-
TEMPERATURE ZONE(S)
TEMPERATURE (℃)
-30℃
TYPE OF VENT SYSTEM
VENT (TIMES/HOUR)
AIR CHANGE (TIMES/HOUR)
-
PALLET(S)
CONTAINER CAPACITY
REEFER PLUG(S)
SIDE DOOR(S)
-
FENDER(S)
-
ANCHOR CHAIN(S)
-
USDA CERTIFICATE
-
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
CHINA
DELIVERY
CHINA
REMARK(S)
