VESSEL NAME
TNK288
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL
FLAG
LUXEMBOURG
PORT OF REGISTRY
-
BUILT YEAR
2008
BUILT PLACE
ADIK TUZLA, TURKEY
CLASSIFICATION
BV
CLASS NOTATION
IMO Ⅱ
SS
2018-03
DD
2018-03
LOA (M)
121.68
LBP (M)
115.60
BEAM (M)
17.20
DEPTH (M)
8.80
SUMMER DRAFT (M)
6.86
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
5268.00
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
2398.00
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
8011.00
WINTER DWT (MT)
-
TROPICAL DWT (MT)
-
DISPLACEMENT (MT)
-
LDT (MT)
-
GEAR(S)
-
M/E(S)
MAK 8L32
M/E POWER (KW)
3840
A/E(S)
3 x LIAG/MAN D2845LE301, 580KW
GENERATOR(S)
-
SHAFT GENERATOR(S)
1 x 1200KW
PROPELLER(S)
VARIABLE PICTH PROPELLER
SPEED /CONSUMPTIONS
13.0KTS, TAKE HOME SYSTEM 9.0KTS
FUEL TYPE
HFO
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
-
COMPARTMENT(S)
6 + 1x SLOP TANK (247CBM)
NUMBER OF CARGO HOLDS
12
CARGO CAPACITY98% (CBFT)
287907
CARGO CAPACITY98% (CBM)
8156
COATING/MATERIAL OF HOLD(S)
PHENOLIC EPOXY
HEATING SYSTEM
SSTEEL HEATING DOUBLE LOOP
SACRIFICIAL ANODE
-
IGS
YES
PUMP(S)
DEEPWELL FRAMO 12 x 330M3/H
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
BOWTHRUSTER 1x 500KW; STERN THRUSTER 2x 450KW
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
WEST AFRICA
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
SBT
CLOSE LOADING SYSTEM
FIXED TANK WASHING
