VESSEL NAME
TNK745
TYPE
OIL/CHEMICAL TANKER
HULL TYPE
DOUBLE HULL/DOUBLE BOTTOM
FLAG
SWEDEN
PORT OF REGISTRY
DONSO
BUILT YEAR
2010
BUILT PLACE
TURKEY
CLASSIFICATION
BV
CLASS NOTATION
I✠Hull✠Mach,Oil tanker ESP,Chemical tanker ESP,
Unrestricted navigation, ✠AUT-UMS , MON-SHAFT , CLEANSHIP 3 , ICE CLASS IA , INWATERSURVEY , VCS
SS
2030-10
DD
2028-05
LOA (M)
129.5
LBP (M)
122.7
BEAM (M)
19.8
DEPTH (M)
10.4
SUMMER DRAFT (M)
8.15
WINTER DRAFT (M)
-
TROPICAL DRAFT (M)
-
GT (MT)
7366
PANAMA GT (MT)
-
SUEZ GT (MT)
-
NT (MT)
3589
PANAMA NT (MT)
-
SUEZ NT (MT)
-
SUMMER DWT (MT)
11215
WINTER DWT (MT)
TROPICAL DWT (MT)
-
DISPLACEMENT (MT)
-
LDT (MT)
-
GEAR(S)
-
M/E(S)
HANSHIN LH46LA, 4499BHP @220RPM
M/E POWER (KW)
3309
A/E(S)
3 x 482 KW @1800RPM
GENERATOR(S)
-
SHAFT GENERATOR(S)
1 x 720KW @900RPM
PROPELLER(S)
CPP
SPEED /CONSUMPTIONS
-
FUEL TYPE
-
BUNKER CAPACITY (CBM)
-
TANKS CAPACITY (CBM)
-
COMPARTMENT(S)
-
NUMBER OF CARGO HOLDS
12+2 SLOP TANKS
CARGO CAPACITY98% (CBFT)
431543
CARGO CAPACITY98% (CBM)
12225
COATING/MATERIAL OF HOLD(S)
MARINELINE
HEATING SYSTEM
STAINLESS STEEL HEATING DOUBLE COILS
SACRIFICIAL ANODE
-
IGS
YES
PUMP(S)
12 x 250 CBM/H
ONE PUMP FOR SINGLE HOLD OR NOT
-
SIDE THRUSTER(S)
BOW THRUSTER 1 x 487KW
INSURANCE
-
CREW
-
ACCOMMODATION
-
INSPECTION
-
DELIVERY
-
PRICE
BUYERS OFFER
REMARK(S)
BWTS
